Applied Materials and CEA-Leti Unveil Joint Lab for Specialty Chip Markets

Based at CEA-Leti, collaboration focuses on materials engineering solutions to accelerate semiconductor device development.

Author Image

By: DAVID SAVASTANO

Editor, Ink World Magazine

Applied Materials, Inc. and CEA-Leti announced an expansion of their longstanding collaboration to focus on developing differentiated materials engineering solutions for several specialty semiconductor applications. The joint lab, which represents CEA-Leti’s highest level of collaboration, aims to accelerate device innovations for Applied’s customers serving ICAPS markets (IoT, Communications, Automotive, Power and Sensors). Technology applications in those fields include photonics, image sen...
